Product Details:
|
Name: | Cast Film Extrusion Machine | Plastic Processed: | LLDPE/LDPE/POE/EVA/Elastomer/Polythylene |
---|---|---|---|
Application: | Sheet/ Film | Material: | Granule |
Frequency: | 380V 3P/50HZ, Single Phase 220v, 50hz | Main Motor Power: | 90KW |
Screw Diameter: | Φ110 | Certification: | CE |
Production Capacity: | 80--120kg/h | Thickness: | 0.015mm--0.1mm |
Weight: | 12T | Dimension(l*w*h): | 15mx4.5mx3.5m |
High Light: | Thermoplastic Elastomer Cast Film Machines,2100mm blown film machine,Thermoplastic blown film machine |
High precision.automatic or manual T-die head, with film thickness automatic detect instrument. with the positive pressure and negative pressure device;on-line marginal film recycling machine will greatly reduce production cost, auto metering counting, automtaic cutting and auto change winding roller. PLC control the winding unit .
Material |
CPE/TPE |
Working width |
1800mm max |
Thickness range |
0.015mm to 0.1mm |
Screw Dia. and L/D |
Φ110×35:1 X 1 |
T die width | 2100mm |
Roller surface length | 2100mm |
Winding Diameter | Φ500 |
Power supply | Three Phase 380V( ±10% )50hz, Single Phase 220V 50Hz |
Mechanical speed: | 30-100m/min |
Extrusion capacity(Maximum) | 100~150kg/h(varies with material) |
Installation power |
About 160kw ( actual consumption is 40%-50% of total installation power) |
Installation space |
L=12M; W=4.5m; H=3.5m
|
Scene of assmebly workshop
