Product Details
Place of Origin: China
Brand Name: DaLi spunbonded non-woven fabric production line serial
Certification: CE
Model Number: DL-1600/2400/3200/S/SS/SMS spunbonded non-woven fabric production line
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: 180000--450000 USD Per Set
Packaging Details: Regular Packing with blanket and stretch film or customized requirment package !
Delivery Time: 2-3 months
Payment Terms: T/T
Supply Ability: 5 sets per month
Name: |
PP Spun Bonded Non-woven Fabric Production Line |
Plastic Processed: |
LLDPE/LDPE/HDPE |
Application: |
Sheet/ Film |
Material: |
Granule |
Voltage: |
380V 3P/50HZ, It Can Be Customized |
Power(w): |
400--1600KW |
Screw Design: |
Single /double Screw Extruder |
Certification: |
CE |
Usage: |
Medical Supplies |
Width: |
1600mm--3200mm |
Weight: |
35T |
Dimension(l*w*h): |
35mx8mx6.5m |
Name: |
PP Spun Bonded Non-woven Fabric Production Line |
Plastic Processed: |
LLDPE/LDPE/HDPE |
Application: |
Sheet/ Film |
Material: |
Granule |
Voltage: |
380V 3P/50HZ, It Can Be Customized |
Power(w): |
400--1600KW |
Screw Design: |
Single /double Screw Extruder |
Certification: |
CE |
Usage: |
Medical Supplies |
Width: |
1600mm--3200mm |
Weight: |
35T |
Dimension(l*w*h): |
35mx8mx6.5m |
spunbonded non-woven ; Non-woven fabric machin;S/SS/SMS spunbonded non-woven fabric production line 1600mm/2400mm/3200mm
S/SS/SMS Spunbonded no-woven fabric Production Line/ 1600/2400/3200
This equipment is a full-automatic one-time plane mask forming machine, which is used for the forming of one-time rectangular ear hanging three drawer mask. It can complete the automatic feeding, moulding, folding, pressure welding and ear band welding of the machine.
This product is used for the production of folding mask production line fully automatic machine,using ultrasonic technology, three to five layers of PP non-woven fabrics, meltblown fabrics, activated carbon and filter materials are fused, non-woven fabrics are fused, ear bands are fused, printed, folded, edge sealed and rolled, can produce 9001,9002 and other folding masks.
According to the raw materials used, the production of masks can reach such as FFP1, FFP2, N95 and other different standards, the whole process without manual operation, all by mechanical production, production is finished.
The product line absorbs the advanced technology from same machines made in other countries, featured with local design complete range of
specifications, superior performance, uniform web formation. With polypropylene as the raw material, the machine can produce white, colorful, ageing resistant, antistatic, antibioetic, flame retardant spun-bonded fabric rolls. The products can be used widely in industries, agriculture, medicine, labor protection, irrgation works, aviation, shoe industrial, packing and daily use artuccle etc.
Key pratmeters of the production line
Model | 1600S | 2400s | 3200s | 1600ss | 2400ss | 3200ss | 1600sms | 2400sms | 3200sms |
Screw Diameter | Ø105-135mm | Ø105-150mm | Ø105-170mm | Ø105-135mm | Ø105-150mm | Ø105-170mm | Ø105-135mm | Ø105-150mm | Ø105-170mm |
L/D | 30:1 | 30:1 | 30:1 | 30:1 | 30:1 | 30:1 | 30:1 | 30:1 | 30:1 |
Output | 1500T/Y | 2000T/Y | 3000T/Y | 2600T/Y | 3800T/Y | 5200T/Y | 3200T/Y | 4700T/Y | 6200T/Y |
Max. Film Width | 1600mm | 2400mm | 3200mm | 1600mm | 2400mm | 3200mm | 1600mm | 2400mm | 3200mm |
Basic Weight | 10-250glm2 | 10-250glm2 | 10-250glm2 | 10-250glm2 | 10-250glm2 | 10-250glm2 | 10-250glm2 | 10-250glm2 | 10-250glm2 |
Fiber Number | 2D-4D | 2D-4D | 2D-4D | 2D-4D | 2D-4D | 2D-4D | 2D-4D | 2D-4D | 2D-4D |
Total Power | 400kw | 550kw | 660kw | 660kw | 800kw | 1200kw | 1100kw | 1300kw | 1600kw |
Speed | 120m/min | 120m/min | 120m/min | 220m/min | 220m/min | 220m/min | 250m/min | 250m/min | 250m/min |
FLow Chart
Recycling raw material + side material—melting and extruding—filtering—measuring—filtering—spinning—cooling—air dragging—air dispersing—air-laid web forming——cooling—winding—slitting—product packing—entering into warehouse—conducting sales.
Scene of the asembly of workshop
