Product Details
Place of Origin: China
Brand Name: DaLi
Certification: CE
Model Number: DL-3300/4300/5300/6300/7300/8300/9300
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: 250000--450000 USD Per Set
Packaging Details: Regular Packing with blanket and stretch film or customized requirment package !
Delivery Time: 2-3 months
Payment Terms: T/T
Supply Ability: 5 sets per month
Name: |
HDPE/LDPE Geomembrane Sheet Productin Line |
Raw Material: |
High-density Polyethylene Resin |
Thickness Of Film: |
30mircometer--250mircometer |
Width: |
Flexible Width 3000mm--9000mm |
Total Power: |
600kw--1600kw |
Size Of Machine: |
25mx12mx4.5m |
Capacity: |
400--1200kg/h |
Raw Material Feeding Device: |
Automatic Feeding Raw Material Device |
Key Points: |
J-times T-die;Siemens PLC Control System,trimming Recycling System |
After-sales Service: |
Rovided: Engineers Available To Service Machinery Overseas |
Name: |
HDPE/LDPE Geomembrane Sheet Productin Line |
Raw Material: |
High-density Polyethylene Resin |
Thickness Of Film: |
30mircometer--250mircometer |
Width: |
Flexible Width 3000mm--9000mm |
Total Power: |
600kw--1600kw |
Size Of Machine: |
25mx12mx4.5m |
Capacity: |
400--1200kg/h |
Raw Material Feeding Device: |
Automatic Feeding Raw Material Device |
Key Points: |
J-times T-die;Siemens PLC Control System,trimming Recycling System |
After-sales Service: |
Rovided: Engineers Available To Service Machinery Overseas |
The conical twin screw is made by high precision special digital screw miller; extruding property can be highly harmonized. It has firstly introduced advanced technique of producing screw with variable pitch and depth, so that the material can be more softly sheared and cut.
The distribution box is specially designed, pull force bearing is fully imported, and the drive life span can be prolonged. It can bear larger extruding pressure.
The electrical system has mainly applied imported parts, it has multiple alarm system, and there are few problems which can be easily eliminated. The cooling system has applied special design, heat emission area is enlarged, the cooling is rapid, and temperature control tolerance can be ± 1degree.
Extra-width Geomembrane/Waterproof Sheet Extrusion Line
Refering to the special request of waterproof and geomembrane industry,JWELL launched a high capacity extrusion line with low shear&energy comsumption.The exclusive design of calender frame and roller structure are helpful to higten the performance of extra-width geomembrane and precision of thickness.
Main technical parameters:
Products |
Smooth sheet,Textured Sheet, Spraying rough sheet, Geotextile composite sheet |
|||||||
Thickness range(mm) |
0.1-3.0mm | |||||||
T-die size(mm) |
2300 | 3300 | 4300 | 5300 | 6300 | 7300 | 8300 | 9300 |
Max working width(mm) |
2000 | 3000 | 4000 | 5000 | 6000 | 7000 | 8000 | 9000 |
Cooling Method |
Circulating water cooling |
